03-04 Cobra Inter-Cooler Coolant System
Our Inter-Cooler Coolant System is for 03-04 Cobra Engines and really any engine that uses the same basic design layout,
meaning a Front Mounted Radiator, Coolant Circulation Pump, Reservoir,
and Inter-Cooler Water to Air Inter-Cooler.
The whole idea of our system is to take the complexity and random component fitting sizes out of the equation, and
give a comprehensive system that supplies the system with coolant through a common size hose with the least amount of restriction
possible. The stock Ford Cobra system is very complex, ugly and expensive to piece together.
It also allows for excessive heat soaking of the coolant lines, which reduces the systems effectiveness.
System fittings, very between 5/8" , 3/4" and 7/8", which makes for problems when trying to connect
a common hose between the many parts of the system. Another huge problem is the ability to disconnect or
remove the parts from the system, weather for repair or for access to other parts. The typical hose connection
is very stiff and generally requires damage to the hose to remove. This isn't that bad for the average
guy that never works on his engine, but for a racer, or car builder that has to mock things up time and again to get the fit
right, or service the engine for basic between round maintenance, this gets to be a problem. The other
consideration is looks, yes all car owners are conscious of who their engines look, and nothing looks worse than a mess of
ugly black rubber hoses. When we designed our Inter-Cooler Hose System,
we had several basic ideals: 1.
Take the complexity out of the
system. We thought it through, so you don't have to. 2. Design a system that flows better than the original
system. We keep the hose sizes maximized to take advantage of better flow, and allow bigger, better
flowing, circulation pumps. 3.
Make it easy to work with.
We have most lines with at least one end pre-terminated, and provide complete instructions. Our
kits come complete with all the Adapters, Reducers, Couplings, Hose, Fittings and Clamps needed, it a complete
kit that solves all the issues. 4.
Design the system so repairs and
maintenance can be performed easier, easy to make and break fittings with rock solid reliability.
Our system converts all the push-on type fittings to a Threaded, AN type System! 5.
Make the system look good, use
quality AN Fittings and Hoses…Plus offer accessories like the Temperature Gauge and Pressure
Gage Kits, to monitor system performance. 6. We use only Oetiker Single Ear Stainless Steel Clamps in our kits, these clamps have
a very sleek and modern look to them, while providing a leak free seal. They provide a custom look and
we even include a set of Oetiker crimping Plies with the kit. 7. Keep it flexible….that
way individuals could use or system on other then stock Cobra Mustangs. All Inter-Cooler system consist
of the same parts, so by offering systems of different lengths, we could accommodate 99% of those wishing to use our system
for their individual application. We supply each push-on fitting, which is
all of the stock fittings, with short sections of AN Hose, one end is attached to the barbed fitting, and the other comes
with a AN Swivel Type Threaded Fitting. Once all the barb or push-on fittings have been converted to our
adapter hoses, then they simply get connected up by similar hoses, with these having AN fittings on both ends, which makes
the connection a breeze, and future disconnection even easier. We can also accommodate any custom layout
you might have, give us a call.
  Inter-Cooler Starter System
Our Starter
System is shown above, it allows you to start your Inter-Cooler system off right, right from the start, at the Inter-Cooler
water coolant connection under the super-charger. Our system uses AN-10 Hose and Fittings to extend the connection out
far enough to start your system and get all connection out from under the Blower Assembly.. The connection at the Inter-Cooler
Manifold, are firmly held in place by Stainless steel one ear Oetiker Clamps, that will not fail. This system allows
quick and leak-proof connections for easy system maintenance and removal of parts.
Starter System comes as shown without
Temperature and Pressure gauges. Gauge Kits sold separately below.
Pressure Gauge Kit One
accessory we have to the Inter-Cooler Coolant Hose
System, is the Pressure Gauge Kit.
This allows you to monitor the system and its Circulation Pump easily. We typically mount it right at the inter-section where
the coolant exits the inter-cooler, But you can mount it anywhere you see fit, If mounted in both the inlet and outlet hoses,
you can monitor system health, by observing the Pressure Differential on each side of the pump. We use a high quality Stainless
Steel, Liquid Filled Pressure Gauge,
and all necessary fittings are included for a easy to install option.
One accessory we have to the Inter-Cooler Coolant Hose System, is the Pressure Gauge Kit. This allows you to monitor the system and its
Circulation Pump easily. We typically mount it right at the inter-section where the coolant exits the inter-cooler, But you
can mount it anywhere you see fit, If mounted in both the inlet and outlet hoses, you can monitor system health, by observing
the Pressure Differential on each side of the pump. We use a high quality Stainless Steel, Liquid Filled Pressure Gauge, and all necessary fittings are included for a easy
to install option. One
accessory we have to the Inter-Cooler Coolant Hose
System, is the Pressure Gauge Kit.
This allows you to monitor the system and its Circulation Pump easily. We typically mount it right at the inter-section where
the coolant exits the inter-cooler, But you can mount it anywhere you see fit, If mounted in both the inlet and outlet hoses,
you can monitor system health, by observing the Pressure Differential on each side of the pump. We use a high quality Stainless
Steel, Liquid Filled Pressure Gauge,
and all necessary fittings are included for a easy to install option. One accessory we have to the Inter-Cooler Coolant Hose System, is the Pressure Gauge Kit. This allows you to monitor the system and its
Circulation Pump easily. We typically mount it right at the inter-section where the coolant exits the inter-cooler, But you
can mount it anywhere you see fit, If mounted in both the inlet and outlet hoses, you can monitor system health, by observing
the Pressure Differential on each side of the pump. We use a high quality Stainless Steel, Liquid Filled Pressure Gauge, and all necessary fittings are included for a easy
to install option. Temperature
Gauge Kit The Temperature Gauge Kit, like the Pressure
Gauge Kit, is for monitoring the Inter-Cooler Coolant System. You have to know what your system is doing
to get the most out of it, and to prevent damage to the engine. Our easy to install system, allows you
to monitor the inter-cooler coolant, either as it enters the inter-cooler or as it exists, or both with two kits.
We use only the best materials, with Stainless Steel Gauge, and all necessary fittings included.
  Inter-Cooler Coolant Circulation Pumps We offer two different Circulation Pumps, one is the stock
Ford 03-04 Cobra - Lightning Pump and the other is a Billet Aluminum Meziere
HP 20 Gal/Min Pump. Both are very popular, and give great service, but the Stock Ford Pump only flows at 6
Gal/Min, while the Meziere pump flows over twice that amount. If purchasing the Meziere Pump,
along with the Coolant Hose Kit, you will get the correct screw in fittings for that pump. The Ford replacement
pump uses Over-Sized Push-on fittings, which are standard in the kit. Please state which pump you are using...
Ford (Bosch) OEM Circulation Pump
We also have the correct wiring connector lead for this pump..just ask
Meziere, Billet Aluminum Circulation Pump
We also have all Radiator Hoses, Heater Hoses and Thromstste Housings available at
Pro Weld. Plus Custom Steering Hoses & AC Hoses!
Top Radiator Hose:………….....Cross-over
to Radiator By-Pass Hose:……………………..Cross-Over
down to Thermostat Housing Bottom Radiator Hose:………..Thermostat
Housing to Radiator Bottom De-Gas Hose:……………………….De-gas
Bottle (reservoir) to Thermostat Housing Engine
Water/Cooler Hose…..Thermostat Housing to Engine Oil Cooler Heater Inlet Hose:…………….…Driver
Side head to Heater Core Heater Outlet Hose:………….…Heater
Core to Fitting on Passenger Side Block
|
